AD844ANZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC393008
Category:
Operational Amplifier, OP Amp IC
Package:
DIP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD844ANZ Operational Amplifier, Single, 1 Amplifier, 60MHz, 2000V/µs, ± 4.5V to ± 18V, DIP, 8Pins
Stock Locations:
Availability:
3 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 11.2

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD844ANZ is a Monolithic Operational Amplifier fabricated using the junction isolated complementary bipolar (CB) process combines high bandwidth and very fast large signal response with excellent DC performance. Although optimized for use in current-to-voltage applications and as an inverting mode amplifier, it is also suitable for use in many non-inverting applications. It can be used in place of traditional op amps, but its current feedback architecture results in much better AC performance, high linearity and an exceptionally clean pulse response. This op amp provides a closed-loop bandwidth that is determined primarily by the feedback resistor and is almost independent of the closed-loop gain. The AD844 is free from the slew rate limitations inherent in traditional op amps and other current-feedback op amps. Peak output rate of change can be over 2000V/µs for a full 20V output step. It can drive 50R loads to ±2.5V with low distortion and is short-circuit protected to 80mA.
Wide bandwidth
20MHz Full power bandwidth, 20V p-p, RL = 500R
100ns to 0.1% Fast settling
0.03% at 4.4MHz Differential gain error
0.16° at 4.4MHz Differential phase error
150µV Maximum offset voltage
6.5mA Quiescent current
ESD sensitive device, take proper precaution while handling the device.

Show

AD844ANZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Supply Voltage (DC)	15.0 V
Supply Current	6.5 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	1.1 W
Common Mode Rejection Ratio	100 dB
Input Capacitance	2.00 pF
Bandwidth	60 MHz
Slew Rate	2.00 kV/μs
Gain Bandwidth Product	60 MHz
Input Impedance	10.0 MΩ
Input Offset Voltage	50 µV
Input Bias Current	200 pA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	60 MHz
Gain Bandwidth	60 MHz
Power Dissipation (Max)	1100 mW
Minimum CMRR Range	100 dB
Supply Voltage (Max)	18 V
	Show
Size-Length	9.27 mm
Size-Width	7.24 mm
Size-Height	3.43 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/12/17
