AD9739BBCZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC914592
Category:
Digital to Analog, DAC IC
Package:
CSP-BGA
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD9739BBCZ Digital to Analog Converter, 14Bit, 2.5GSPS, Serial, 1.7V to 1.9V, 3.1V to 3.5V, CSPBGA, 160Pins
Stock Locations:
Availability:
662 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 34.06

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD9739BBCZ is a 14-bit high performance RF Digital-to-analog Converter (DAC) capable of synthesizing wideband signals from dc up to 3GHz. Its DAC core features a quad-switch architecture that provides exceptionally low distortion performance with an industry-leading direct RF synthesis capability. This feature enables multicarrier generation up to the Nyquist frequency in baseband mode as well as second and third Nyquist zones in mix mode. The output current can be programmed over the 8.66 to 31.66mA range. A dual-port, source synchronous, LVDS interface simplifies the digital interface with existing FGPA/ASIC technology. On-chip controllers are used to manage external and internal clock domain variations over temperature to ensure reliable data transfer from the host to the DAC core. Multichip synchronization is possible with an on-chip synchronization controller. A serial peripheral interface (SPI) is used for device configuration as well as read-back of status registers.
