AD9851BRSZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC145212
Category:
Voltage Reference
Package:
SSOP-28
Datasheet:
Datasheet 3D Model
Description:
Special Function IC, Direct Digital Synthesizer, 180MHz, 10Bit DAC, 2.7V to 5.25V, SSOP-28
Stock Locations:
Availability:
1,000 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 27.88

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD9851BRSZ is a CMOS 180MHz DDS/DAC Synthesizer that uses advanced DDS technology, coupled with an internal high speed, high performance D/A converter and comparator to form a digitally programmable frequency synthesizer and clock generator function. When referenced to an accurate clock source, it generates a stable frequency and phase-programmable digitized analogue output sine wave. This sine wave can be used directly as a frequency source or internally converted to a square wave for agile-clock generator applications. The DDS contains a unique 6x REFCLK multiplier circuit that eliminates the need for a high speed reference oscillator and has minimal impact on SFDR and phase noise characteristics. This provides five bits of programmable phase modulation resolution to enable phase shifting of its output in increments of 11.25°.
180MHz Clock rate with selectable 6x reference clock multiplier
On-chip high performance 10-bit DAC and high speed comparator with hysteresis
>43dB SFDR
32-bit Frequency tuning word
Parallel or serial simplified control interface
Asynchronous loading format
5-bit Phase modulation and offset capability
ESD sensitive device, take proper precaution while handling the device.
