Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Case/Package | DIP |
Pin Pitch | 2.54 mm |
Contact Plating | Gold Flash |
Voltage Rating (DC) | 24 V |
Insulation Resistance | 1.00 GΩ |
Orientation | Vertical |
Contacts Type | SPST |
Number of Circuits | 8 Circuit |
Number of Positions | 8 Position |
Contact Resistance | 50.0 mΩ |
Contact Current Rating | 100mA @24VDC |
Current Rating (Max) | 0.1A @24VDC |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -30 ℃ |
Voltage Rating (DC Max) | 24 V |
Maximum Contact Resistance (Max) | 50 mΩ |
Show | |
Size-Length | 22.3 mm |
Size-Width | 8.38 mm |
Size-Height | 5.8 mm |
Contact Material | Copper Alloy |
Operating Temperature | -30℃ ~ 85℃ |
Product Lifecycle Status | Unknown |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/06/15 |
HTS Code | 8536509032 |
ECCN Code | EAR99 |
