Description

Product Details
The ADF5901 is a 24 GHz Tx monolithic microwave integrated circuit (MMIC) with an on-chip, 24 GHz VCO with PGA and dual Tx channels for radar systems. The on-chip, 24 GHz VCO generates the 24 GHz signal for the two Tx channels and the LO output. Each Tx channel contains a power control circuit. There is also an on-chip temperature sensor.
Control of all the on-chip registers is through a simple 4-wire interface.
The ADF5901 comes in a compact 32-lead, 5 mm × 5 mm LFCSP package.
Applications
Automotive radars
Industrial radars
Microwave radar sensors
Industrial sensors
Precision instrumentation
Tank level sensors
Smart sensors
Door opening
Energy saving
Commercial sensors: object detection and tracking
Cars, boats, aircraft, and UAVs (drones): collision avoidance
Intelligent transportation systems: intelligent traffic monitoring and control
Surveillance and security
### Features and Benefits
24 GHz to 24.25 GHz voltage controlled oscillator (VCO)
2-channel 24 GHz power amplifier (PA) with 8 dBm output
Single-ended outputs
2-channel muxed outputs with mute function
Programmable output power
N divider output (frequency discriminator)
24 GHz local oscillator (LO) output buffer
250 MHz signal bandwidth
Power control detector
Auxiliary 8-bit ADC
±5°C temperature sensor
4-wire serial peripheral interface (SPI)
Electrostatic discharge (ESD) performance
Human body model (HBM): 2000 V
Charged device model (CDM): 250 V
Qualified for automotive applications
