ADG1634BRUZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC2435863
Category:
Analog Switch Ic, Analog Switch Multiplexer
Package:
TSSOP-20
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADG1634BRUZ Analog Switch, Quad Channel, SPDT, 4Channels, 4.5Ω, ± 3.3V to ± 18V, 3.3V to 16V, TSSOP
Stock Locations:
Availability:
203 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.65

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADG1634BRUZ is a single-pole double-throw (SPDT) monolithic quad iCMOS® Analog Switch exhibit break-before-make switching action that prevents momentary shorting when switching channels. It uses an EN input to enable or disable the devices. When disabled, all channels are switched off. The ultralow on resistance and on-resistance flatness of these switches make them ideal solutions for data acquisition and gain switching applications, where low distortion is critical. iCMOS construction ensures ultralow power dissipation, making the parts ideally suited for many applications.
No VL supply required
3V Logic-compatible inputs
Rail-to-rail operation
1R On-resistance flatness
Up to 206mA continuous current

Show

ADG1634BRUZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	TSSOP-20
Number of Outputs	8 Output
Supply Current	300 µA
Number of Circuits	4 Circuit
Number of Channels	4 Channel
Number of Positions	20 Position
Power Dissipation	12.0 nW
Bandwidth	103 MHz
Number of Inputs	4 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	109 MHz
	Show
Size-Length	6.6 mm
Size-Width	4.5 mm
Size-Height	1.2 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
