Image is for your reference only,please check specifications for details

ADG508FBRNZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC767233
Category:
Analog Switch Ic, Analog Switch Multiplexer
Package:
SOIC-16
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADG508FBRNZ 8:1 Analog Multiplexer IC, Single, 300Ω, 10.8V to 16.5V, SOIC-16
Stock Locations:
Availability:
1,330 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.53

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADG508F series CMOS Analog Multiplexer comprising eight single channels. These multiplexers provide fault protection. Using a series n-channel, p-channel, n-channel MOSFET structure, both device and signal source protection is provided in the event of an overvoltage or power loss. During fault conditions with power supplies off, the multiplexer input (or output) appears as an open circuit and only a few nanoamperes of leakage current will flow. This protects not only the multiplexer and the circuitry driven by the multiplexer, but also protects the sensors or signal sources that drive the multiplexer. The ADG508F switches one of eight inputs to a common output as determined by the 3-bit binary address lines A0, A1 and A2. An EN input on each device is used to enable or disable the device and when disabled, all channels are switched off.
All switches OFF with power supply OFF
Analog output of on channel clamped within power supplies if an overvoltage occurs
Latch-up proof construction
Fast switching times - tON 230ns maximum, tOFF 130ns maximum
Low power dissipation (3.3mW maximum)
Fault and overvoltage protection (-40V to +55 V)
Break-before-make construction
TTL and CMOS compatible inputs

Show

ADG508FBRNZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	15.0V (max)
Number of Outputs	1 Output
Contacts Type	DPST-NC
Supply Current	100 nA
Number of Circuits	1 Circuit
Number of Channels	8 Channel
Number of Positions	16 Position
Drain to Source Resistance (on) (Rds)	300 Ω
Power Dissipation	0.0033 W
Number of Inputs	8 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	13.5V ~ 16.5V
Supply Voltage (Max)	16.5 V
Supply Voltage (Min)	10.8 V
	Show
Size-Length	10 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
