ADG723BRMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC198533
Category:
Analog Switch Ic, Analog Switch Multiplexer
Package:
MSOP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADG723BRMZ Analog Switch, Dual Channel, SPST, 2Channels, 4Ω, 1.8V to 5.5V, MSOP, 8Pins
Stock Locations:
Availability:
368 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 2.68

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADG723BRMZ is a single-pole single-throw (SPST) dual monolithic CMOS Analog Switch designed on an advanced submicron process that provides low power dissipation yet gives high switching speed, low on resistance and low leakage currents. It is designed to operate from a single 1.8 to 5.5V supply, making them ideal for use in battery-powered instruments and with the new generation of DACs and ADCs. It conducts equally well in both directions when on. The ADG723 exhibits break-before-make switching action.
Low on-resistance flatness
>200MHz (-3dB) Bandwidth
Fast switching times
TTL/CMOS Compatible
<0.1µW Low power consumption

Show

ADG723BRMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package (SI)	SOP
Case/Package	MSOP-8
Supply Voltage (DC)	5.50V (max)
Number of Outputs	2 Output
Contacts Type	SPST
Supply Current	1 nA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	8 Position
Drain to Source Resistance (on) (Rds)	4.00 Ω
Number of Bits	2 Bit
Power Dissipation	0.45 W
Bandwidth	200 MHz
Number of Inputs	2 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	200 MHz
Supply Voltage	1.8V ~ 5.5V
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
