- ADIS16210CMLZ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC9628040
-
Category:Acceleration Sensor, Accelerometer
-
Datasheet:Datasheet 3D Model
-
Description:ANALOG DEVICES ADIS16210CMLZ MEMS Accelerometer, Precision Tri-Axial, Digital, X, Y, Z, 1.7g, 3V, 3.6V, Module
-
Stock Locations:
-
Availability:323 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 339.48
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The ADIS16210CMLZ is a Precision Tri-axial Inclinometer that provides precise measurements for both pitch and roll angles over a full orientation range of ±180°. It combines a MEMS tri-axial acceleration sensor with signal processing, addressable user registers for data collection/programming and a SPI-compatible serial interface. In addition, the production process includes unit specific calibration for optimal accuracy performance. It also offers digital temperature sensor and power supply measurements together with configuration controls for many applications. The MEMS sensor elements are bound to an aluminium core for tight platform coupling and excellent mechanical stability. An internal clock drives the data sampling system, which eliminates the need for an external clock source. The SPI and data buffer structure provide convenient access to accurate sensor data and configuration controls.
- ±180° Measurement range, roll and pitch axes
- Digital internal temperature measurements
- Digital internal power supply measurements
- Programmable user calibration options
- Single command, frame alignment
- Manual accelerometer bias correction
- Programmable operation and control
- Sample rate/filtering
- Alarm conditions and indicator output
- SPI-compatible serial interface
- Product features proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy electrostatic discharges.
ADIS16210CMLZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 15 Pin |
| Supply Voltage (DC) | 3.00V (min) |
| Supply Current | 18 mA |
| Number of Positions | 15 Position |
| Bandwidth | 50 Hz |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Voltage Rating | 3V ~ 3.6V |
| Supply Voltage | 3V ~ 3.6V |
| Supply Voltage (Max) | 3.6 V |
| Supply Voltage (Min) | 3 V |
| Show | |
| Size-Length | 24 mm |
| Size-Height | 15 mm |
| Operating Temperature | -40℃ ~ 125℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Each |
| RoHS | RoHS Compliant |
| Lead-Free Status | Contains Lead |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/12/17 |
| ECCN Code | EAR99 |
