ADIS16228CMLZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1764726
Category:
Acceleration Sensor, Accelerometer
Package:
Aluminum Package with Flex Connector
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADIS16228CMLZ MEMS Accelerometer, Digital Tri-Axial, Digital, X, Y, Z, ± 18g, 3V, 3.6V, Module
Stock Locations:
Availability:
278 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 551.02

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADIS16228CMLZ is an digital triaxial vibration sensor with FFT analysis and storage with 15 lead module with connector interface. The ADIS16228 iSensor is a complete vibration sensing system that combines triaxial acceleration sensing with advanced time domain and frequency domain signal processing. Time domain signal processing includes a programmable decimation filter and selectable windowing function. Frequency domain processing includes a 512 point, real valued FFT for each axis, along with FFT averaging, which reduces the noise floor variation for finer resolution. The 14 record FFT storage system offers users the ability to track changes over time and capture FFTs with multiple decimation filter settings.
Frequency domain triaxial vibration sensor
Flat frequency response up to 5KHz
Digital acceleration data of ±18g measurement range
Real time sample mode of 20.48KSPS, single axis
Capture sample modes of 20.48KSPS, three axes
FFT, 512-point, real valued, all three axes (x, y, z)
Storage of 14 FFT records on all three axes (x, y, z)
Programmable alarms, 6 spectral bands
Internal self-test with status flags
Digital temperature and power supply measurements
