Image is for your reference only,please check specifications for details
- ADIS16490BMLZ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC11155132
-
Category:Motion Sensor
-
Package:ML-24-9
-
Datasheet:Datasheet 3D Model
-
Description:Inertial Sensor Digital Output 3.3V Automotive 24Pin MSM LAMINATE Tray
-
Stock Locations:
-
Availability:315 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 2844.01
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Product Details
- The ADIS16490 is a complete inertial system that includes a triaxis gyroscope and a triaxis accelerometer. Each inertial sensor in the ADIS16490 combines industry leading iMEMS® technology with signal conditioning that optimizes dynamic performance. The factory calibration characterizes each sensor for sensitivity, bias, alignment, and linear acceleration (gyroscope bias). As a result, each sensor has its own dynamic compensation formulas that provide accurate sensor measurements.
- The ADIS16490 provides a simple, cost effective method for integrating accurate, multiaxis inertial sensing into industrial systems, especially when compared with the complexity and investment associated with discrete designs. All necessary motion testing and calibration are part of the production process at the factory, greatly reducing system integration time. Tight orthogonal alignment simplifies inertial frame alignment in navigation systems. The SPI and register structure provide a simple interface for data collection and configuration control.
- The ADIS16490 uses the same footprint and connector system as the ADIS16375, ADIS16480, ADIS16485, and ADIS16488A, which greatly simplifies the upgrade process. The ADIS16490 is packaged in a module that is approximately 47 mm × 44 mm × 14 mm and includes a standard connector interface.
- **Applications**
- Precision instrumentation, stabilization
- Guidance, navigation, control
- Avionics, unmanned vehicles
- Precision autonomous machines, robotics
- ### Features and Benefits
- Triaxial, digital gyroscope, ±100°/sec dynamic range
- ±0.05° axis to axis misalignment error
- ±0.25° axis to package misalignment error
- 1.8°/hr in run bias stability
- 0.09°/√hr angular random walk
- Triaxial, digital accelerometer, ±8 _g_
- 3.6 μ_g_ in run bias stability
- Triaxial, delta angle and delta velocity outputs
- Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C
- Serial peripheral interface (SPI) compatible
- Programmable operation and control
- Automatic and manual bias correction controls
- 4 finite impulse response (FIR) filter banks, 120 configurable taps
- Digital input/output (I/O): data ready, external clock
- Sample clock options: internal, external, or scaled
- On demand self test of inertial sensors
- Single-supply operation: 3.0 V to 3.6 V
- 2000 _g_ shock survivability
- Operating temperature range: −40°C to +105°C
ADIS16490BMLZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Number of Pins | 24 Pin |
| Case/Package | ML-24-9 |
| Bandwidth | 480 Hz |
| Operating Temperature (Max) | 105 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Show | |
| Operating Temperature | -40℃ ~ 105℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Tray |
| RoHS | RoHS Compliant |
| Lead-Free Status | |
| ECCN Code | 7A994 |
| HK STC License | NLR |
