Image is for your reference only,please check specifications for details

TL064CDT - ST Microelectronics
Manufacturer:
ST Microelectronics
ManyChip's Part#:
MC4242925
Category:
Operational Amplifier, OP Amp IC
Package:
SOIC-14
Datasheet:
Datasheet 3D Model
Description:
STMICROELECTRONICS TL064CDT Operational Amplifier, Quad, 4 Amplifier, 1MHz, 3.5V/µs, 6V to 36V, SOIC, 14Pins
Stock Locations:
Availability:
1,275 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.26

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TL064CDT is a low-power high-speed quad JFET input Operational Amplifier incorporates well matched, high-voltage JFET and bipolar transistors in a monolithic integrated circuit. The device features high slew rates, low input bias and offset currents and a low offset voltage temperature coefficient.
Wide common-mode (up to VCC+) and differential voltage ranges
Output short-circuit protection
High input impedance JFET input stage
Internal frequency compensation
Latch-up free operation
200µA Very low power consumption
680mW Power dissipation

Show

TL064CDT Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SOIC-14
Operating Voltage	7V ~ 36V
Supply Current	200 µA
Number of Circuits	4 Circuit
Number of Channels	4 Channel
Number of Positions	14 Position
Power Dissipation	680 mW
Common Mode Rejection Ratio	76 dB
Bandwidth	1 MHz
Slew Rate	3.50 V/μs
Gain Bandwidth Product	1 MHz
Input Offset Voltage	3 mV
Input Bias Current	30 pA
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Gain Bandwidth	1 MHz
Power Dissipation (Max)	680 mW
Minimum CMRR Range	70 dB
Supply Voltage	6V ~ 36V
	Show
Size-Length	8.75 mm
Size-Width	4 mm
Size-Height	1.65 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
