Description

Product Details
The ADL5606 is a broadband, two-stage, 1 W RF driver amplifier that operates over a frequency range of 1800 MHz to 2700 MHz. The device can be used in a wide variety of wired and wireless applications, including ISM, MC-GSM, W-CDMA, TD-SCDMA, and LTE.
The ADL5606 operates on a 5 V supply voltage and a supply current of 362 mA. The driver also incorporates a fast power-up/power-down function for TDD applications, applications that require a power saving mode, and applications that intermittently transmit data.
The ADL5606 is fabricated on a GaAs HBT process and is packaged in a compact 4 mm × 4 mm, 16-lead LFCSP that uses an exposed paddle for excellent thermal impedance. The ADL5606 operates from −40°C to +85°C. A fully populated evaluation board tuned to 2140 MHz is also available.
**Applications**
Wireless infrastructure
Automated test equipment
ISM/AMR applications
### Features and Benefits
Operation from 1800 MHz to 2700 MHz
Gain of 24.3 dB at 2140 MHz
OIP3 of 45.5 dBm at 2140 MHz
P1dB of 30.8 dBm at 2140 MHz
Noise figure of 4.7 dB at 2140 MHz
Power supply: 5 V
Power supply current: 362 mA typical
Internal active biasing
Fast power-up/power-down function
Compact 4 mm × 4 mm, 16-lead LFCSP
ESD rating of ±1 kV (Class 1C)
Pin-compatible with the ADL5605 (700 MHz to 1000 MHz)

Show
