ADTL082ARMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC2514540
Category:
Operational Amplifier, OP Amp IC
Package:
MSOP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADTL082ARMZ Operational Amplifier, Single, 1 Amplifier, 5MHz, 20V/µs, 8V to 36V, MSOP, 8Pins
Stock Locations:
Availability:
239 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.27

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADTL082ARMZ is a single JFET input Operational Amplifier provides industry-leading performance over TL08x devices. The ADTL082A is improved versions of TL08x A, I and Q grades. The ADTL08x family offers lower noise, offset voltage, offset drift over temperature and bias current over the TL08x. In addition, the ADLT08x family has better common-mode rejection and slew rates. This op amp is ideal for various applications, including process control and instrumentation equipment, active filtering, data conversion, buffering and power control and monitoring.
Unity-gain stable
10pA Maximum low input bias current
16nV/√Hz Low noise
80dB Minimum CMRR
0.001% Total harmonic distortion
1.2mA Typical supply current

Show

ADTL082ARMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Supply Current	1.2 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	80 dB
Bandwidth	5 MHz
Slew Rate	20.0 V/μs
Gain Bandwidth Product	5 MHz
Input Impedance	1.00 TΩ
Input Offset Voltage	1.5 mV
Input Bias Current	2 pA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	5 MHz
Supply Voltage	8V ~ 36V
Supply Voltage (Max)	36 V
Supply Voltage (Min)	8 V
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
