ADUM1100URZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC444644
Category:
Interface Isolator, Digital Isolator
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADUM1100URZ Digital Isolator, 1Channel, 10.5ns, 3V, 5.5V, NSOIC, 8Pins
Stock Locations:
Availability:
209 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 2.16

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADUM1100 series Digital Isolator combines high speed CMOS and monolithic air core transformer technology. This isolation component provides outstanding performance characteristics superior to alternatives, such as optocoupler devices. Configured as a pin-compatible replacement for existing high speed optocouplers, the ADuM1100 supports data rates as high as 25 and 100Mbps. It operates with a voltage supply ranging from 3 to 5.5V, boasts a propagation delay of <18ns and edge asymmetry of <2ns and is compatible with temperatures up to 125°C. It operates at very low power, less than 0.9mA of quiescent current (sum of both sides) and a dynamic current of less than 160µA per Mbps of data rate. Unlike other optocoupler alternatives, the ADuM1100 provides dc correctness with a patented refresh feature that continuously updates the output signal.
>25kV/µs High common-mode transient immunity
Low power operation
High data rate of DC to 100Mbps (NRZ)

Show

ADUM1100URZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	3.00V (min)
Rise/Fall Time	3 ns
Output Current	≤20.0 mA
Supply Current	9 mA
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	240 mW
Data Rate	100 Mbps
Rise Time	3 ns
Isolation Voltage	2500 Vrms
Input Current (Min)	10 μA
Maximum Forward Voltage (Max)	5 V
Fall Time (Max)	3 ns
Fall Time (Max)	3 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	240 mW
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	Show
Size-Length	5 mm
Size-Width	4 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
