ADUM5411BRSZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC985747
Category:
Interface Isolator, Digital Isolator
Package:
SSOP-24
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES ADUM5411BRSZ Digital Isolator, 4Channel, 13ns, 1.7V, 5.5V, SSOP, 24Pins New
Stock Locations:
Availability:
207 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 111.78

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADUM5411BRSZ is a robust 2.5KVrms quad channel isolator with integrated DC to DC converters in 24 lead SSOP package. This digital isolator has isoPower integrated, isolated DC to DC converters. Based on the Analogue Devices iCoupler technology, the DC to DC converters provide regulated, isolated power that is adjustable between 3.15V and 5.25V. The ADuM5411 eliminates the need for a separate, isolated DC to DC converter in low power, isolated designs. The iCoupler chip scale transformer technology is used for isolated logic signals and for the magnetic components of DC to DC converters. The result is a small form factor, total isolation solution. It is typically used in RS232 transceivers, isolated sensor interfaces, power supply start-up bias and gate drives.
3 inputs at VDD1 side and 1 inputs at VISO side
Maximum data rate of 150Mbps
Maximum propagation delay of 13ns at 5V
Maximum pulse width distortion of 3ns
Up to 150mW output power
High common mode transient immunity of 100KV/µs
Operating temperature range from -40°C to +105°C
ESD sensitive device. Proper ESD precautions should be taken to avoid performance degradation and loss of functionality.

Show

ADUM5411BRSZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	24 Pin
Case/Package	SSOP-24
Rise/Fall Time	2.5 ns
Number of Channels	4 Channel
Power Dissipation	2.5 W
Isolation Voltage	3.75 kVrms
Fall Time (Max)	2.5 ns
Fall Time (Max)	2.5 ns
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	2500 mW
Supply Voltage	1.7V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	1.7 V
	Show
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2016/06/20
ECCN Code	EAR99
