ADV7127 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC389422260
Datasheet:
Datasheet 3D Model
Description:
CMOS 240MHz 10Bit High Speed Video DAC
Stock Locations:
Availability:
240 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Product Details
The ADV7127 is a high speed, DAC on a single monolithic chip. It consists of a 10-bit, video DAC with an on-board voltage reference, complementary outputs, a standard TTL input interface, and high impedance analog output current sources.
The ADV7127 has a 10-bit wide input port. A single 5 V or 3.3 V power supply and clock are all that are required to make the device functional.
The ADV7127 is fabricated in a complementary metal-oxide semiconductor (CMOS) process. Its monolithic CMOS construction ensures greater functionality with low power dissipation. The ADV7127 is available in a 24-lead TSSOP package which includes a power-down mode and an on-board voltage reference circuit.
**Product Highlights**
1. 240 MSPS throughput.
2. Guaranteed monotonic to 10 bits.
3. Compatible with a wide variety of high resolution color graphics systems including RS-343A and RS-170.
**Applications**
Digital video systems (1600 × 1200 at 100 Hz)
High resolution color graphics
Digital radio modulation
Image processing
Instrumentation
Video signal reconstruction
Direct digital synthesis (DDS)
Wireless local area networks (LANs)
### Features and Benefits
240 MSPS throughput rate
10-bit digital-to-analog converter (DAC)
RS-343A-/RS-170-compatible output
Complementary outputs
DAC output current range: 2 mA to 18.5 mA
TTL-compatible inputs
Internal voltage reference
Single supply 5 V or 3.3 V operation
24-lead thin shrink small outline package (TSSOP) package
Low power dissipation
Low power standby mode
Power-down mode
Industrial temperature range (−40°C to +85°C)
