ALF1P24 Panasonic - Power Relay - ManyChip Electronics

Image is for your reference only,please check specifications for details

ALF1P24 - Panasonic
Manufacturer:
Panasonic
ManyChip's Part#:
MC21347361
Category:
Power Relay
Package:
-
Datasheet:
Datasheet 3D Model
Description:
Реле питания/сигнала, SPST, импульсное, 0,038 А (катушка), 24 В пост. тока (катушка), 900 мВт (катушка), вход пост. тока, выход перем. тока, сквозной монтаж (прямой), СООТВЕТСТВУЕТ ТРЕБОВАНИЯМ ROHS
Stock Locations:
Availability:
721 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 3.83

Updated at 21/09/2026 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Силовое реле серии LF(ALF) на 20 А, подходящее для бытовой техники. Идеально подходит для нагрузок компрессоров и инверторов. Имеет пути утечки и зазоры между контактами и катушкой.
Высокое сопротивление изоляции
Доступны типы для печатных плат (PCB) и для поверхностного монтажа (TMP)
Соответствует различным стандартам безопасности

Show

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	4 Pin
Case/Package	-
Voltage Rating (AC)	250 V
Current Rating	20 A
Insulation Resistance	1000 MΩ
Contacts Type	SPST-NO
Power Consumption	900 mW
Contact Current Rating	20 A
Coil Voltage	24 VDC
Coil Current	37.5 mA
Coil Resistance	640 Ω
Carry Current	20.0 A
Coil Voltage (DC)	24 V
Coil Power	900 mW
Rating Power (Max)	6.25 KVA
Switching Current (Max)	25 A
Operating Temperature (Max)	60 ℃
Operating Temperature (Min)	-40 ℃
	Show
Size-Length	30.1 mm
Size-Width	23.3 mm
Size-Height	23.3 mm
Contact Material	Silver Tin Oxide
Operating Temperature	-40℃ ~ 60℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
HTS Code	8536490075
ECCN Code	EAR99
