- BA3121N - ROHM Semiconductor
-
Manufacturer:ROHM Semiconductor
-
ManyChip's Part#:MC120535118
-
Category:Audio Amplifier IC
-
RoHS:Lead free / RoHS Compliant
-
Datasheet:Datasheet 3D Model
-
Description:Dual Channel 18V 900mW 1.5dB Ground Isolation Audio Amplifier - SIP-8
-
Stock Locations:
-
Availability:680 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.36
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The BA3121,BA3121F and BA3121N are ground isolation amplifiers developed for use in car audio applications. These ICs efficiently eliminate problems caused by wiring resistance, and remove noise generated by the electrical devices used in automobiles. The capacitance values of the external capacitors required for the ICs are small to allow compact and reliable set design.
- Features
- 1) Large capacitors not required
- 2) High common-mode rejection ratio (57dB typ. at f = 1kHz).
- 3) Low noise (VNO= 3.5µVrms Typ.).
- 4) Low distortion (THD = 0.002% Typ.).
- 5) Two channels.
BA3121N Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Case/Package | SIP-8 |
| Supply Current | 9 mA |
| Number of Channels | 2 Channel |
| Power Dissipation | 900 mW |
| Common Mode Rejection Ratio | 57 dB |
| Slew Rate | 2.00 V/μs |
| Output Power | 900 mW |
| Gain | 1.5 dB |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -30 ℃ |
| Power Dissipation (Max) | 900 mW |
| Supply Voltage | 4V ~ 18V |
| Show | |
| Size-Length | 19.3 mm |
| Size-Width | 2.8 mm |
| Size-Height | 5.8 mm |
| Operating Temperature | -30℃ ~ 85℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
