Image is for your reference only,please check specifications for details

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The BAS 4002A RPP E6327 is a 4-pin Bridge Rectifier Diode for polarity independence, reverse polarity protection and low loss bridge rectification. The low VF Schottky diode array allows 40V reverse voltage and 0.2A forward current.
Fast switching
Switching speed and low voltage drop
For high energy efficiency rectifiers
Very small systems
Full and half bridge
Suitable also for advanced reverse polarity protection

Show

BAS4002ARPPE6327HTSA1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	4 Pin
Case/Package	TO-253-4
Number of Positions	4 Position
Forward Voltage	0.69 V
Max Repetitive Reverse Voltage (Vrrm)	40V
Forward Current	200 mA
Max Forward Surge Current (Ifsm)	2 A
Maximum Forward Voltage (Max)	790 mV
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
	Show
Size-Length	2.9 mm
Size-Width	1.3 mm
Size-Height	0.9 mm
Operating Temperature	150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
ECCN Code	EAR99
