Description
- Summary of Features:
- General-purpose diode for high-speed switching
- Circuit protection
- Voltage clamping
- High-level detecting and mixing
- BAS70-04S: For orientation in reel see
- package information below
- Pb-free (RoHS compliant) package1)
- Qualified according AEC Q101
BAS7004WH6327XTSA1 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 3 Pin |
| Case/Package | SOT-323-3 |
| Load Current | 0.07 A |
| Number of Positions | 3 Position |
| Forward Voltage | 1V @15mA |
| Power Dissipation | 250 mW |
| Reverse recovery time | 100 ps |
| Forward Current | 70 mA |
| Max Forward Surge Current (Ifsm) | 100 mA |
| Maximum Forward Voltage (Max) | 1 V |
| Forward Current (Max) | 70 mA |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Junction Temperature | 150℃ (Max) |
| Power Dissipation (Max) | 250 mW |
| Show | |
| Size-Length | 2 mm |
| Size-Width | 1.25 mm |
| Size-Height | 0.9 mm |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
