BQ24002PWP - TI
Manufacturer:
TI
ManyChip's Part#:
MC37826400
Category:
Battery Management IC
Package:
HTSSOP-20
Datasheet:
Datasheet 3D Model
Description:
Battery Charge Management Linear 1-cell Li-Ion Battery Charger w/Integrated FET, Two LED Linear Charge Management Li-Ion 1200mA 4.1V/4.2V 20Pin HTSSOP EP Tube
Stock Locations:
Availability:
289 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 3.18

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The BQ24002PWP is an advanced Li-ion linear Charge Management Device for highly integrated and space-limited applications. That combines high-accuracy current and voltage regulation; FET pass-transistor and reverse-blocking Schottky, battery conditioning, temperature, or input-power monitoring; charge termination; charge-status indication; and charge timer in a small package. The bq2400x measures battery temperature using an external thermistor. It inhibits charge until the battery temperature is within the user-defined thresholds. Alternatively, the user can monitor the input voltage to qualify charge. The bq2400x series then charge the battery in three phases, preconditioning, constant current and constant voltage. If the battery voltage is below the internal low-voltage threshold, the charger uses low-current pre-charge to condition the battery.
High-accuracy voltage regulation (±1%)
Safety-charge timer during preconditioning and fast charge
Optional temperature or input-power monitoring before and during charge
Charge termination by minimum current and time
Low-power sleep mode
Green product and no Sb/Br
Device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.

Show

BQ24002PWP Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	HTSSOP-20
Supply Voltage (DC)	10.0V (max)
Input Voltage (DC)	10.0 V
Output Current	1.2 A
Number of Positions	20 Position
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	-20 ℃
Supply Voltage	4.5 V
Supply Voltage (Max)	10 V
Input Voltage	10 V
	Show
Size-Length	6.5 mm
Size-Width	4.4 mm
Size-Height	1.15 mm
Operating Temperature	-40℃ ~ 70℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
