BQ24130EVM - TI
Manufacturer:
TI
ManyChip's Part#:
MC14504563
Category:
Microprocessor Development Kit
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS BQ24130EVM Evaluation Module, Power Management, Li-Ion Battery Charger, BQ24130
Stock Locations:
Availability:
9 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 119.55

Updated at 09/07/2026 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The BQ24130EVM is an Evaluation Module for evaluate the operation and performance of BQ24130 600kHz synchronous switch-mode Li-Ion and Li-Polymer host-controlled battery charger with integrated MOSFETs. The bq24130 is highly integrated host-controlled Li-ion and Li-polymer switch-mode battery charge controllers with two integrated N-channel power MOSFETs. It offers a constant-frequency synchronous PWM controller with high accuracy regulation of charge current and voltage. It also provides charge status monitoring. The bq24130 automatically enters a low-quiescent current sleep mode when the input voltage falls below the battery voltage. The bq24130 charges one, two or three cell (selected by CELL pin), supporting up to 4A charge current.
Integrated 20V N-MOSFETs CELL pin setting up to 12.6V battery voltage 1, 2 or 3-cell with 4.2V/cell
Input operating range 4.5 to 17V
LED indication for charge status
Test points for key signals available for testing purpose - easy probe hook-up
Jumpers available - easy to change setting
