BTS721L1 - Infineon
Manufacturer:
Infineon
ManyChip's Part#:
MC4561342
Category:
Analog Switch Ic, Analog Switch Multiplexer
Package:
PG-DSO-20
Datasheet:
Datasheet 3D Model
Description:
Buffer/Inverter Based Peripheral Driver, 4 Driver, 9.8A, MOS, PDSO20, GREEN, PLASTIC, SOP-20
Stock Locations:
Availability:
1,800 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.18

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The BTS721L1 is a 4-output high-side vertical Power FET Switch with charge pump, ground referenced CMOS compatible input and diagnostic feedback. It is monolithically integrated in smart SIPMOS® technology, providing embedded protective functions, under-voltage and overvoltage shutdown with auto-restart and hysteresis.
Overload protection
Current limitation
Short-circuit protection
Thermal shutdown
Overvoltage protection
Fast demagnetization of inductive loads
Reverse battery protection
Open drain diagnostic output
Open load detection in ON-state
Loss of ground and loss of VBB protection
Electrostatic discharge (ESD) protection
High voltage capability
Benchmark energy robustness
ESD sensitive device, take proper precaution while handling the device.

Show

BTS721L1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	PG-DSO-20
Power Rating	3.7 W
Number of Outputs	4 Output
Input Voltage (DC)	16.0 V
Output Current	2.9 A
Supply Current	8 mA
Number of Channels	4 Channel
Number of Positions	20 Position
Power Dissipation	3.7 W
Output Current (Max)	2.5 A
Output Current (Min)	2.5 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	3700 mW
Supply Voltage	5V ~ 34V
Supply Voltage (Max)	34 V
Supply Voltage (Min)	5 V
Input Voltage	16 V
	Show
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
