CD74HC4511E - TI
Manufacturer:
TI
ManyChip's Part#:
MC5931103
Category:
Logic Controller, Logic IC
Package:
DIP-16
Datasheet:
Datasheet 3D Model
Description:
BCD to Seven-Segment Decoder / Driver / Latch, HC Family, 7 Output, 10mA, 4.5V to 5.5V, DIP-16
Stock Locations:
Availability:
131 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.7

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The CD74HC4511E is a 1-channel high speed CMOS logic BCD-to-7 Segment Latch/Decoder/Driver with four address inputs D0 to D3, an active-low blanking (BL) input, lamp-test (LT) input and a latch-enable (LE) input that, when high, enables the latches to store the BCD inputs. When LE is low, the latches are disabled, making the outputs transparent to the BCD inputs. This device has standard-size output transistors, but is capable of sourcing (at standard VOH levels) up to 7.5mA at 4.5V. The HC types can supply up to 10mA at 6V.
Input latches for BCD code storage
Lamp test and blanking capability
Balanced propagation delays and transition times
Significant power reduction compared to LSTTL logic ICs
CMOS Input compatibility

Show

CD74HC4511E Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP-16
Supply Voltage (DC)	4.50V (min)
Number of Outputs	7 Output
Output Current	5.20 mA
Supply Current	8 µA
Number of Circuits	2 Circuit
Number of Positions	16 Position
Number of Bits	7 Bit
Bandwidth	28.0 MHz
Number of Inputs	4 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Supply Voltage	2V ~ 6V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	Show
Size-Length	19.69 mm
Size-Width	6.35 mm
Size-Height	4.57 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
