Description
- Make an effective common gate amplifier using this CSD17501Q5A power MOSFET from Texas Instruments. Its maximum power dissipation is 3200 mW. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This device is made with nexfet technology. This MOSFET transistor has a minimum operating temperature of -55 °C and a maximum of 150 °C. This N channel MOSFET transistor operates in enhancement mode.
CSD17501Q5A Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | VSON-FET-8 |
| Number of Channels | 1 Channel |
| Polarity | N-CH |
| Power Dissipation | 3.2 W |
| Threshold Voltage | 1.3 V |
| Drain to Source Voltage (Vds) | 30 V |
| Continuous Drain Current (Ids) | 28A |
| Rise Time | 17 ns |
| Input Capacitance (Ciss) | 2630pF @15V(Vds) |
| Input Power (Max) | 3.2 W |
| Fall Time | 7.9 ns |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 3.2W (Ta) |
| Show | |
| Operating Temperature | -55℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
| ECCN Code | EAR99 |
