Image is for your reference only,please check specifications for details
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- CX Series AC Output SIP Relay
- ** 5 Amp; 120, 240, 380, 480 VAC; AC SIP Package**
- Crydom"s family of SPST-NO relays achieves one of the highest power switching capability in a PC-mounted air-cooled package. Advanced features include exceptional steady state current, plus ultra-high surge ratings.* Operating Temperature Range:** –30°C to 80°C. ** Isolation Voltage (VAC):** 4000\. ** Available Option:** -B — Normally closed (CX240D5 only). ** M Series:** MP packaging (relay is inserted into plastic case filled with epoxy).
- ** Features**
- * AC or DC Control, SCR Output
- * Ultra-High Surge Rating
- * UL, CSA, VDE Approved
CXE240D5 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 4 Pin |
| Case/Package | SIP-4 |
| Supply Voltage (DC) | 32.0V (max) |
| Operating Voltage | 280V (max) |
| Current Rating | 5 A |
| Capacitance | 10 pF |
| Output Voltage | 12V ~ 280V |
| Output Current | 5000 mA |
| Contacts Type | SPST-NO |
| Load Current | 5 A |
| Input Current | 15 mA |
| Isolation Voltage | 4000 v |
| Input Impedance | 1500 Ω |
| Input Voltage (Max) | 32 V |
| Input Voltage (Min) | 15 V |
| Output Voltage (Max) | 280 V |
| Output Current (Max) | 5 A |
| Input Current (Min) | 15 mA |
| Load Current (Max) | 5 A |
| Load Current (Min) | 0.06 A |
| Operating Temperature (Max) | 80 ℃ |
| Operating Temperature (Min) | -30 ℃ |
| Voltage Rating | 280 VAC |
| Operating Voltage (Min) | 12 Vrms |
| Operating Voltage (Max) | 280 Vrms |
| Input Voltage | 15VDC ~ 32VDC |
| Show | |
| Size-Length | 43.1 mm |
| Size-Width | 7.60 mm |
| Size-Height | 25.4 mm |
| Operating Temperature | -30℃ ~ 80℃ |
| Product Lifecycle Status | Active |
| Packaging | Bulk |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| HTS Code | 8536490080 |
| ECCN Code | EAR99 |
