Image is for your reference only,please check specifications for details
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The D2440D is a Solid State Relay with thermally conductive epoxy encapsulation, DPST-NO contacts, zero crossing switching mode and quick-connect terminals. This dual-series panel mount relay has independently controlled dual output solid-state relay.
- DC control
- SCR output for heavy industrial loads
- 4000Vrms Dielectric strength
- 300R Nominal input impedance
- 1/2 cycle ms Turn-on/off maximum time
- -40 to 80°C Ambient operating temperature range
- Disconnect all power before installing or working with this equipment. Risk of material damage and hot enclosure.
D2440D Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | Hockey Puck |
| Current Rating | 40 A |
| Output Voltage | 24V ~ 280V |
| Output Current | 40000 mA |
| Contacts Type | DPST-NO |
| Load Current | 40 A |
| Input Current | 13 mA |
| Resistance | 310 Ω |
| Isolation Voltage | 4000 v |
| Input Voltage (Max) | 15 V |
| Input Voltage (Min) | 4 V |
| Output Voltage (Max) | 280 V |
| Output Current (Max) | 40 A |
| Input Current (Min) | 13 mA |
| Load Current (Max) | 40 A |
| Load Current (Min) | 0.15 A |
| Operating Temperature (Max) | 80 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Voltage Rating | 280 VAC |
| Operating Voltage (Min) | 24 VAC |
| Operating Voltage (Max) | 280 VAC |
| Input Voltage | 4VDC ~ 15VDC |
| Show | |
| Size-Length | 45.7 mm |
| Size-Width | 33.3 mm |
| Size-Height | 21.6 mm |
| Operating Temperature | -40℃ ~ 80℃ |
| Product Lifecycle Status | Active |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| HTS Code | 8536490080 |
| ECCN Code | EAR99 |
