Image is for your reference only,please check specifications for details
- DAC08CS - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC1158533
-
Category:Digital to Analog, DAC IC
-
Package:SOIC-16
-
Datasheet:Datasheet 3D Model
-
Description:Digital to Analog Converter 1Channel Current Steering 8Bit 16Pin SOIC N
-
Stock Locations:
-
Availability:2,415 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 2.68
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- GENERAL DESCRIPTION
- The DAC08 series of 8-bit monolithic digital-to-analog convert ers provide very high speed performance coupled with low cost and outstanding applications flexibility.
- FEATURES
- Fast settling output current: 85 ns
- Full-scale current prematched to ±1 LSB
- Direct interface to TTL, CMOS, ECL, HTL, PMOS
- Nonlinearity to 0.1% maximum over temperature range
- High output impedance and compliance: −10 V to +18 V
- Complementary current outputs
- Wide range multiplying capability: 1 MHz bandwidth
- Low FS current drift: ±10 ppm/°C
- Wide power supply range: ±4.5 V to ±18 V
- Low power consumption: 33 mW @ ±5 V
- Low cost
DAC08CS Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 16 Pin |
| Case/Package | SOIC-16 |
| Supply Voltage (DC) | 18.0V (max) |
| Number of Outputs | 1 Output |
| Output Voltage | 18.0 V |
| Output Current | 2.10 mA |
| Number of Channels | 1 Channel |
| Number of Bits | 8 Bit |
| Power Dissipation | 0.174 W |
| Sample Rate | 11.8 Msps |
| Resolution (Bits) | 8.0 Bit |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 174 mW |
| Number of DACs | 1 DAC |
| Supply Voltage (Max) | 36 V |
| Supply Voltage (Min) | 9 V |
| Show | |
| Size-Height | 1.5 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
| Mil-Spec | Yes |
| ECCN Code | EAR99 |
