DAC8413FPCZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1084688
Category:
Digital to Analog, DAC IC
Package:
PLCC-28
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES DAC8413FPCZ Digital to Analogue Converter, Quad, 12Bit, Parallel, ± 5V to ± 15V, LCC, 28Pins
Stock Locations:
Availability:
292 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 55.63

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The DAC8413FPCZ is a quad 12-bit voltage output Digital-to-analog Converter (DAC) with read-back capability. Output voltage swing is set by the two reference inputs VREFH and VREFL. By setting the VREFL input to 0V and VREFH to a positive voltage, the DAC provides unipolar positive output range. A similar configuration with VREFH at 0V and VREFL at a negative voltage provides unipolar negative output range. Bipolar outputs are configured by connecting both VREFH and VREFL to non-zero voltages. This method of setting output voltage range has advantages over other bipolar offsetting methods because it is not dependent on internal and external resistors with different temperature coefficients. Digital controls allow the user to load or read back data from any DAC, load any DAC and transfer data to DAC at one time. An active low RESET load of DAC output registers to zero scale for the DAC8413.
Built using a complementary BiCMOS process
True voltage output
Double-buffered inputs
Reset to minimum
Fast bus access time

Show

DAC8413FPCZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	28 Pin
Case/Package	PLCC-28
Operating Voltage	5V ~ 15V
Number of Outputs	4 Output
Supply Current	8.5 mA
Number of Channels	4 Channel
Number of Positions	28 Position
Number of Bits	12 Bit
Power Dissipation	0.33 W
Resolution (Bits)	12.0 Bit
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	330 mW
Number of DACs	4 DAC
	Show
Size-Length	11.58 mm
Size-Width	11.58 mm
Size-Height	3.94 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	Yes
REACH SVHC Compliance Edition	2016/06/20
