DB2X41400L - Panasonic
Manufacturer:
Panasonic
ManyChip's Part#:
MC75476169
Category:
Schottky Diode
Package:
Mini2-F4-B
Datasheet:
Datasheet 3D Model
Description:
PANASONIC ELECTRONIC COMPONENTS DB2X41400L Schottky Rectifier, 40V, 2A, Single, SOD-123, 2Pins, 490mV
Stock Locations:
Availability:
0 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The DB2X41400L is a silicon epitaxial planar Schottky Barrier Diode suitable for high frequency rectification.
Low forward-voltage VF
Average forward current
Halogen-free
MSL 1 Compliant
UL94V-0 Flammability rating

Show

DB2X41400L Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	Mini2-F4-B
Number of Positions	2 Position
Forward Voltage	490mV @2A
Reverse recovery time	30 ns
Forward Current	2 A
Max Forward Surge Current (Ifsm)	15 A
Maximum Forward Voltage (Max)	490 mV
Forward Current (Max)	2 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Junction Temperature	125℃ (Max)
	Show
Size-Length	2.6 mm
Size-Width	1.6 mm
Size-Height	0.8 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Unknown
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
