DS90CR286AMTD - TI
Manufacturer:
TI
ManyChip's Part#:
MC36824966
Category:
Interface IC, Interface Controller
Package:
TSSOP-56
Datasheet:
Datasheet 3D Model
Description:
+3.3V Rising Edge Data Strobe LVDS Receiver 28Bit Channel Link - 66MHz 56-TSSOP -40℃ to 85℃
Stock Locations:
Availability:
1,897 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.9

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The DS90CR286AMTD is a 3.3V Rising Edge Data Strobe LVDS Receiver converts the four LVDS data streams back into parallel 28-bits of LVCMOS data. The output of the receiver strobes on the rising edge. The receiver LVDS clock operates at rates from 20 to 66MHz. The device phase-locks to the input clock, samples the serial bit streams at the LVDS data lines and converts them into parallel output data. At an incoming clock rate of 66MHz, each LVDS input line is running at a bit rate of 462Mbps, resulting in a maximum throughput of 1.848Gbps. This device is an enhanced over prior generation receivers and provide a wider data valid time on the receiver output.
Best-in-class set and hold times on RxOUTPUTs
PLL requires no external components
Compatible with TIA/EIA-644 LVDS standard
<200µW Maximum Rx power-down mode
50% Duty cycle on receiver output clock

Show

DS90CR286AMTD Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	56 Pin
Case/Package	TSSOP-56
Supply Voltage (DC)	3.00V (min)
Supply Current	81.0 mA
Number of Positions	56 Position
Power Dissipation	1890 W
Data Rate	1.85 Gbps
Power Consumption	258 W
Input Current (Min)	10 μA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1890 mW
Supply Voltage	3V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	3 V
	Show
Size-Length	14 mm
Size-Width	6.1 mm
Size-Height	0.9 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	5A991.b.1
