Image is for your reference only,please check specifications for details
- DSA30I150PA - IXYS Semiconductor
-
Manufacturer:IXYS Semiconductor
-
ManyChip's Part#:MC111782804
-
Category:TVS Diode
-
RoHS:Lead free / RoHS Compliant
-
Datasheet:Datasheet 3D Model
-
Description:DSA30 Series 150V 30A Single Schottky Diode GEN 2 Flange Mount - TO-220-2
-
Stock Locations:
-
Availability:150 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 1.33
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Schottky Diode Gen²
- Features / Advantages:
- ● Very low Vf
- ● Extremely low switching losses
- ● low Irm values
- ● Improved thermal behaviour
- ● High reliability circuit operation
- ● Low voltage peaks for reduced protection circuits
- ● Low noise switching
- Applications:
- ● Rectifiers in switch mode power supplies (SMPS)
- ● Free wheeling diode in low voltage converters
DSA30I150PA Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 2 Pin |
| Case/Package | TO-220-2 |
| Forward Voltage | 930mV @30A |
| Power Dissipation | 175 W |
| Maximum Forward Voltage (Max) | 930mV @30A |
| Forward Current (Max) | 30 A |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 175000 mW |
| Show | |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
