Image is for your reference only,please check specifications for details

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

ELLVGG2R2N Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Number of Pins	2 Pin
Case/Package	3mm x 3mm x 1.5mm
Current Rating	1.6 A
Capacitance Tolerance	±30 %
Inductance	2.2 µH
Self Resonant Frequency	100 kHz
Part Family	ELLVGG
Resistance	92.0 mΩ
Resonant Frequency	100 kHz
Inductance Tolerance	±30 %
Test Frequency	100 kHz
Resistance (DC Max)	0.092 Ω
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	1.5 mm
Product Lifecycle Status	Unknown
Packaging	Cut Tape (CT)
Minimum Packing Quantity	2000
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
