Description

The ESM6045DV is a NPN Darlington Power Module designed for welding equipment, SMPS and UPS as well as DC/DC and DC/AC converters. Fast switching times and very low saturation voltage resulting in reduced switching and conduction losses.
High current power bipolar module
Very low Rth junction case
Specified accidental overload areas
Ultra fast freewheeling diode
Fully insulated
Easy to mount
Low internal parasitic inductance
Well-controlled hFE parameter for increased reliability

Show

ESM6045DV Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	4 Pin
Case/Package	ISOTOP
Voltage Rating (DC)	450 V
Current Rating	84.0 A
Load Current	84 A
Number of Positions	4 Position
Polarity	NPN
Power Dissipation	250 W
Breakdown Voltage (Collector to Emitter)	450 V
Continuous Collector Current	84A
hFE Min	120 @70A, 5V
Input Power (Max)	250 W
DC Current Gain (hFE)	120
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	250000 mW
	Show
Size-Length	38.2 mm
Size-Width	25.5 mm
Size-Height	9.1 mm
Operating Temperature	150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
