Image is for your reference only,please check specifications for details
- EVQPLMA15 - Panasonic
-
Manufacturer:Panasonic
-
ManyChip's Part#:MC16021836
-
Category:Tactile Switch, Jog Switch
-
Package:SMD
-
Datasheet:Datasheet 3D Model
-
Description:Keypad Switch, 1 Switches, SPST, Momentary, 0.02A, 15VDC, 3.2N, Solder Terminal, Surface Mount-straight
-
Stock Locations:
-
Availability:0 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0
Updated at 02/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The EVQPLMA15 is a single-pole single-throw 1.5mm height square SMD Light Touch Tactile Switch with push plate. Snap action/Push-on type, surface mount for reflow soldering.
- 50MR insulation resistance
- 250V Dielectric strength
- 200000 Minimum operations
EVQPLMA15 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Case/Package | SMD |
| Voltage Rating (DC) | 15 V |
| Actuator Type | Standard |
| Current Rating | 20 mA |
| Number of Rows | 2 Row |
| Orientation | Vertical |
| Contacts Type | SPST-NO |
| Contact Current Rating | 20.0 mA |
| Current Rating (Max) | 0.02A @15VDC |
| Operating Temperature (Max) | 70 ℃ |
| Operating Temperature (Min) | -20 ℃ |
| Voltage Rating | 15 VDC |
| Voltage Rating (DC Max) | 15 V |
| Maximum Contact Resistance (Max) | 50 mΩ |
| Show | |
| Size-Length | 4.9 mm |
| Size-Width | 4.9 mm |
| Size-Height | 1.5 mm |
| Operating Temperature | -20℃ ~ 70℃ |
| Product Lifecycle Status | Unknown |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
| ECCN Code | EAR99 |
