Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 4 Pin |
Case/Package | 4-Mini-Flat |
Rise/Fall Time | 5µs, 5.5µs |
Output Voltage | 75 V |
Number of Channels | 1 Channel |
Number of Positions | 4 Position |
Forward Voltage | 1.35 V |
Input Current | 10.0 mA |
Power Dissipation | 40 mW |
Rise Time | 5 µs |
Isolation Voltage | 3750 Vrms |
Forward Current | 20 mA |
Output Voltage (Max) | 75 V |
Input Current (Min) | 20 mA |
Reverse Breakdown Voltage | 6 V |
Maximum Forward Voltage (Max) | 1.8 V |
Forward Current (Max) | 20 mA |
Fall Time | 5.5 µs |
Operating Temperature (Max) | 125 ℃ |
Operating Temperature (Min) | -40 ℃ |
Power Dissipation (Max) | 150 mW |
Show | |
Size-Height | 2.11 mm |
Operating Temperature | -40℃ ~ 125℃ |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/06/15 |
