Description

Dealing with high voltages and currents? Protect your circuit with the FSDM311A power switch, developed by Fairchild Semiconductor. This charge controller has single output. This device has a maximum power dissipation of 1400 mW. It features 14 Ohm switch on resistance. This device has a supply current of 1.5 mA and a minimum output current of 0.5(Max) A. Its maximum power dissipation is 1400 mW. This product comes in rail packaging to keep individual parts separated and protected. This charge controller has an operating temperature range of -25 °C to 85 °C.

Show

FSDM311A Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Power Rating	13 W
Number of Outputs	1 Output
Input Voltage (DC)	20.0 V
Output Voltage	650 V
Output Current	0.5 A
Breakdown Voltage	650 V
Supply Current	1.5 mA
Number of Positions	8 Position
Power Dissipation	1.4 W
Switching Frequency	67 kHz
Duty Cycle	67 %
Maximum Duty Cycle	74 %
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-25 ℃
Power Dissipation (Max)	1400 mW
Input Voltage	20 V
	Show
Size-Length	9.83 mm
Size-Width	6.67 mm
Size-Height	3.68 mm
Operating Temperature	-25℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
