Image is for your reference only,please check specifications for details
- GT50J325 - Toshiba
-
Manufacturer:Toshiba
-
ManyChip's Part#:MC53472604
-
Category:IGBT Transistor, IGBT Module
-
Package:TO-3
-
Datasheet:Datasheet 3D Model
-
Description:IGBT Single Transistor, 50A, 2.45V, 240W, 600V, TO-3P, 3Pins
-
Stock Locations:
-
Availability:193 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 10.29
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The GT50J325 from Toshiba is a N channel silicon insulated gate bipolar transistor in through hole TO-3P package. IGBT typically used at fast switching and high power switching applications.
- Fourth generation IGBT
- Enhancement mode type
- Fast switching
- Operating frequency up to 50KHz
- Maximum collector emitter saturation voltage of 2.45V
- FRD included between emitter and collector
- Collector emitter voltage VCES of 600V
- DC collector current of 50A
- Junction temperature of 150°C
- Collector power dissipation of 240W
GT50J325 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 3 Pin |
| Case/Package | TO-3 |
| Number of Positions | 3 Position |
| Polarity | N-Channel |
| Power Dissipation | 240 W |
| Rise Time | 70 ns |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Junction Temperature (Max) | 150 ℃ |
| Show | |
| Operating Temperature | -55℃ ~ 150℃ |
| Product Lifecycle Status | Not Recommended |
| RoHS | RoHS Compliant |
