Description

Product Details
The HMC1144 is a gallium arsenide (GaAs), pseudomorphic high electron mobility transfer (pHEMT), monolithic microwave integrated circuit (MMIC), distributed power amplifier that operates from 35 GHz to 70 GHz. In the lower band of 35 GHz to 50 GHz, the HMC1144 provides 19 dB (typical) of gain, 28 dBm output IP3, and 19 dBm and 19.5 dBm, respectively, of output P1dB gain compression. In the upper band of 50 GHz to 70 GHz, the HMC1144 provides 19 dB (typical) of gain, 32 dBm output IP3, and 21 dBm of output power at 1 dB gain compression. The HMC1144 requires 320 mA from a 4 V supply. The HMC1144 amplifier inputs/outputs are internally matched to 50 Ω, facilitating integration into multichip modules (MCMs). All data is taken with the chip connected via two 0.025 mm (1 mil) wire bonds of 0.076 mm (3 mil) minimal length.
**Applications**
Test instrumentation
Microwave radios and very small aperture terminals (VSATs)
Military and space
Telecommunications infrastructure
Fiber optics
### Features and Benefits
Output power for 1 dB compression (P1dB): 21 dBm typical
Saturated output power (PSAT): 22 dBm typical
Gain: 19 dB typical
Output third-order intercept (IP3): 28 dBm typical
Supply voltage: 4 V at 320 mA
50 Ω matched input/output
Die size: 2.3 mm × 1.8 mm × 0.102 mm
