Description

This instrumentation amplifier INA101SM differential amplifier, developed by Texas Instruments, can use both channels in order to amplify an audio signal. Its maximum power dissipation is 600 mW. Its typical dual supply voltage is ±15 V, with a minimum of ±5 V and maximum of ±20 V. This part has a temperature range of -55 °C to 125 °C. It has a single channel per chip. This device uses dual power supplies.

Show

INA101SM Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	10 Pin
Case/Package	TO-100-10
Supply Current	6.7 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Power Dissipation	0.6 W
Common Mode Rejection Ratio	80 dB
Quiescent Current	6.70 mA
Bandwidth	25.0 MHz
Slew Rate	400 mV/μs
Input Offset Voltage	10 µV
Input Bias Current	10 nA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
3dB Bandwidth	300 kHz
Power Dissipation (Max)	600 mW
Supply Voltage (Max)	30V ~ 50V
	Show
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Not Recommended for New Designs
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
HK STC License	NLR
