Description

VDSS= 55V
RDS(on)= 6.5mΩ
ID= 75A
Description
Specifically designed for Automotive applications, this HEXFET® Power MOSFET utilizes the latest processing techniques to achieve extremely low on resistance per silicon area. Additional features of this design are a 175°C junction operating temperature, fast switching speed and improved repetitive avalanche rating . These features combine to make this design an extremely efficient and reliable device for use in Automotive applications and a wide variety of other applications.
Features
Advanced Process Technology
Ultra Low On-Resistance
175°C Operating Temperature
Fast Switching
Repetitive Avalanche Allowed up to Tjmax
Lead-Free

Show

IRF3205ZSPBF Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	TO-263-3
Voltage Rating (DC)	55.0 V
Current Rating	75.0 A
Power Rating	170 W
Polarity	N-Channel
Power Dissipation	170 W
Part Family	IRF3205ZS
Input Capacitance	3.45 nF
Gate Charge	110 nC
Drain to Source Voltage (Vds)	55 V
Continuous Drain Current (Ids)	75.0 A
Rise Time	95.0 ns
Input Capacitance (Ciss)	3450pF @25V(Vds)
Input Power (Max)	170 W
	Show
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
