IRF5806TRPBF Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	TSOT-23-6
Power Rating	2 W
Number of Positions	6 Position
Drain to Source Resistance (on) (Rds)	0.0471 Ω
Polarity	P-Channel
Power Dissipation	2 W
Threshold Voltage	1.2 V
Drain to Source Voltage (Vds)	20 V
Continuous Drain Current (Ids)	4A
Rise Time	27 ns
Input Capacitance (Ciss)	594pF @15V(Vds)
Fall Time	126 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	2W (Ta)
	Show
Size-Length	3.1 mm
Size-Width	1.7 mm
Size-Height	1 mm
Material	Silicon
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
