Image is for your reference only,please check specifications for details
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Single P-Channel 60 V 0.5 Ohms Through Hole Power Mosfet - HVMDIP-4
IRFD9014PBF Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 4 Pin |
| Case/Package | DIP-4 |
| Power Rating | 1.3 W |
| Number of Positions | 4 Position |
| Drain to Source Resistance (on) (Rds) | 0.5 Ω |
| Polarity | P-Channel |
| Power Dissipation | 1.3 W |
| Input Capacitance | 270 pF |
| Drain to Source Voltage (Vds) | 60 V |
| Continuous Drain Current (Ids) | -1.10 A |
| Rise Time | 63 ns |
| Input Capacitance (Ciss) | 270pF @25V(Vds) |
| Input Power (Max) | 1.3 W |
| Fall Time | 31 ns |
| Operating Temperature (Max) | 175 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 1.3 W |
| Show | |
| Size-Length | 5 mm |
| Size-Width | 6.29 mm |
| Size-Height | 3.37 mm |
| Operating Temperature | -55℃ ~ 175℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| Minimum Packing Quantity | 2500 |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
