Image is for your reference only,please check specifications for details
- ISO150AU - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC47839736
-
Category:Interface Isolator, Digital Isolator
-
Package:SOIC-28
-
Datasheet:Datasheet 3D Model
-
Description:General Purpose Digital Isolator 1500Vrms 2Channel 80MBd 1.6kV/μs (Typ) CMTI 28-SOIC (0.295", 7.5mm Width) 12 Leads
-
Stock Locations:
-
Availability:1,125 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 14.65
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- General Purpose Digital Isolator 1500Vrms 2 Channel 80MBd 1.6kV/µs (Typ) CMTI 28-SOIC (0.295", 7.50mm Width), 12 Leads
ISO150AU Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 12 Pin |
| Case/Package | SOIC-28 |
| Supply Voltage (DC) | 3.00V (min) |
| Rise/Fall Time | 9 ns |
| Supply Current | 14.0 mA |
| Number of Circuits | 2 Circuit |
| Number of Channels | 2 Channel |
| Number of Positions | 12 Position |
| Data Rate | 80.0 Mbps |
| Isolation Voltage | 1500 Vrms |
| Thermal Shutdown | No |
| Fall Time (Max) | 14 ns |
| Fall Time (Max) | 14 ns |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 3V ~ 5.5V |
| Supply Voltage (Max) | 5.5 V |
| Supply Voltage (Min) | 3 V |
| Show | |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Not Recommended for New Designs |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
