Description
- The ISO3088DW is an isolated full-duplex RS-485 differential Line Transceiver ideal for long transmission lines because the ground loop is broken to allow for a much larger common-mode voltage range. The symmetrical isolation barrier of the device is tested to provide 2500Vrms of isolation for 60s per UL 1577 between the bus-line transceiver and the logic-level interface. Any cabled I/O can be subjected to electrical noise transients from various sources. This noise transient can cause damage to the transceiver and/or nearby sensitive circuitry if they are of sufficient magnitude and duration. This isolated device can significantly increase protection and reduce the risk of damage to expensive control circuits.
- Thermal shutdown protection
- 16pF Typical low bus capacitance
- 50kV/µs Typical transient immunity
- Fail-safe receiver for bus open, short or idle
- Meets or exceeds TIA/EIA RS-485 requirements
- Green product and no Sb/Br
- This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
ISO3088DW Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 16 Pin |
| Case/Package | SOIC-16 |
| Supply Voltage (DC) | 3.15V (min) |
| Output Current | 10 mA |
| Supply Current | 15 mA |
| Number of Channels | 3 Channel |
| Number of Positions | 16 Position |
| Data Rate | 20.0 Mbps |
| Isolation Voltage | 2500 Vrms |
| Thermal Shutdown | Yes |
| Drivers Per Package | 1 |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 3.15.5.5 VDC |
| Supply Voltage (Max) | 5.5 V |
| Supply Voltage (Min) | 3.15 V |
| Show | |
| Size-Length | 10.28 mm |
| Size-Width | 7.52 mm |
| Size-Height | 2.35 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| ECCN Code | EAR99 |
