Image is for your reference only,please check specifications for details
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Protect your electronic components and circuit from dangerous electrostatic discharge with this tvs ITA25B3 ESD protection device from STMicroelectronics. This ESD diode has a maximum ESD protection device voltage of 15@Air Gap/8@Contact Disc/25@HBM kV. This device"s maximum clamping voltage is 36 V. This ESD diode has an operating temperature range of -55 °C to 125 °C. Its capacitance value is 420 pF. It is made in a array 9 configuration.
ITA25B3 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 20 Pin |
| Case/Package | SOIC-20 |
| Voltage Rating (DC) | 25.0 V |
| Capacitance | 420 pF |
| Power Rating | 300 W |
| Number of Circuits | 9 Circuit |
| Clamping Voltage | 36 V |
| Test Current | 1 mA |
| Peak Pulse Power | 300 W |
| Min Breakdown Voltage | 25 V |
| Reverse Breakdown Voltage | 25 V |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Show | |
| Size-Length | 13.0 mm |
| Size-Width | 7.60 mm |
| Size-Height | 2.35 mm |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
