Image is for your reference only,please check specifications for details
- KSZ8001L - Microchip
-
Manufacturer:Microchip
-
ManyChip's Part#:MC13000470
-
Category:Ethernet Controller IC, Ethernet Controller
-
Package:LQFP-48
-
Datasheet:Datasheet 3D Model
-
Description:PHY 1CH 10Mbps/100Mbps 1.8V/3.3V 48Pin LQFP Tray
-
Stock Locations:
-
Availability:200 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 3.84
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The KSZ8001L is an Integrated 9-port 10/100 Switch with PHY and frame buffer. This device runs in two modes. The first mode is an eight port integrated switch and the second is as a nine port switch with the ninth port available through an MII (Media Independent Interface). Useful configurations include a stand-alone eight port switch as well as an eight port switch with a routing element connected to the extra MII port. The additional port is also useful for a public network interfacing. The KS8999 is designed to reside in an unmanaged design not requiring processor intervention. This is achieved through I/O strapping or EEPROM programming at system reset time. On the media side, it supports 10BaseT, 100BaseTX and 100BaseFX as specified by the IEEE 802.3 committee. Physical signal transmission and reception are enhanced through use of analog circuitry that makes the design more efficient and allows for lower power consumption and smaller chip die size.
- 128kB of SRAM on chip for frame buffering
- 2.0Gbps High performance memory bandwidth
- Wire speed reception and transmission
- Integrated address look-up engine, supports 1K absolute MAC addresses
- Automatic address learning, address aging and address migration
- Supports 802.1p priority and port based priority
- Supports port based VLAN
- Supports 1536byte frame for VLAN tag
- Supports DiffServ priority, 802.1p based priority or port based priority broadcast storm protection
- Proven transceiver technology for UTP and fibre operation
- Supports for UTP or fibre on all 8-ports
- Indicators for link, activity, full/half-duplex and speed
- Full duplex IEEE 802.3x flow control
- Half-duplex back pressure flow control
- Supports MDI/MDI-X auto crossover
KSZ8001L Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 48 Pin |
| Case/Package | LQFP-48 |
| Supply Current | 52 mA |
| Number of Channels | 1 Channel |
| Number of Positions | 48 Position |
| Power Dissipation | 250 mW |
| Data Rate | 100 Mbps |
| Operating Temperature (Max) | 70 ℃ |
| Operating Temperature (Min) | 0 ℃ |
| Power Dissipation (Max) | 250 mW |
| Supply Voltage | 1.8V, 3.3V |
| Supply Voltage (Max) | 1.89 V |
| Supply Voltage (Min) | 1.71 V |
| Show | |
| Size-Length | 7 mm |
| Size-Width | 7 mm |
| Size-Height | 1.4 mm |
| Operating Temperature | 0℃ ~ 70℃ |
| Product Lifecycle Status | Unknown |
| Packaging | Tray |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance Edition | 2014/06/16 |
| ECCN Code | 5A991.B |
