Image is for your reference only,please check specifications for details

L165V - ST Microelectronics
Manufacturer:
ST Microelectronics
ManyChip's Part#:
MC116111670
Category:
Amplifier, Buffer IC
Package:
Pentawatt-5
Datasheet:
Datasheet 3D Model
Description:
STMICROELECTRONICS L165V Operational Amplifier, Single, 1 Amplifier, 100kHz, 8V/µs, ± 6V to ± 18V, Pentawatt, 5Pins
Stock Locations:
Availability:
3,669 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 21.58

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

DESCRIPTION
The L165 is a monolithic integrated circuit in Pen tawatt® package, intended for use as power operational amplifier in a wide range of applications, including servo amplifiers and power supplies. The high gain and high output power capability provide superiore performance wherever an operational amplifier/power booster combination is required.
■OUTPUT CURRENT UP TO 3A
■LARGE COMMON-MODE AND DIFFERENTIAL MODE RANGES
■SOA PROTECTION
■THERMAL PROTECTION ± 18V SUPPLY

Show

L165V Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	5 Pin
Case/Package	Pentawatt-5
Supply Voltage (DC)	18.0V (max)
Power Rating	20 W
Supply Current	40 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	5 Position
Power Dissipation	20 W
Common Mode Rejection Ratio	70 dB
Bandwidth	100 kHz
Slew Rate	8.00 V/μs
Gain	80.0 dB
Input Offset Voltage	2 mV
Input Bias Current	200 nA
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	18 V
	Show
Size-Length	10.4 mm
Size-Width	4.8 mm
Size-Height	9.2 mm
Operating Temperature	-40℃ ~ 100℃
Product Lifecycle Status	Not Recommended for New Designs
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
