Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Solder |
Number of Pins | 9 Pin |
Case/Package | throughHole |
Number of Contacts | 9 Contact |
Gender | Male |
Contact Plating | Gold Flash |
Current Rating | 5 A |
Insulation Resistance | 1000 MΩ |
Number of Rows | 2 Row |
Number of Positions | 9 Position |
Number of Mating Cycles | 250 Cycle |
Current Rating (Max) | 5 A |
Operating Temperature (Max) | 105 ℃ |
Operating Temperature (Min) | -55 ℃ |
Voltage Rating | 250 V |
Operating Voltage (Max) | 250 VAC |
Maximum Contact Resistance (Max) | 20 mΩ |
Show | |
Size-Length | 30.84 mm |
Size-Width | 12.55 mm |
Size-Height | 12.55 mm |
Color | Black |
Contact Material | Brass |
Operating Temperature | -55℃ ~ 155℃ |
Product Lifecycle Status | Active |
Packaging | Tray |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
ECCN Code | EAR99 |
